機能

商用や学術研究、教育などに理想的な
４種類のパッケージ

・基本パッケージとなる "BoB/Research"

・筋電図解析を追加した "BoB/EMG"

・人間工学分析を追加した "BoB/Ergo"

・教育用に最適な "BoB/Teaching"

各パッケージの機能一覧Functionality

機能 BoB/Research BoB/EMG BoB/Ergo BoB/Teaching
Point position/vel/acc ● ● ● ●
Velocity vectors ● ● ● ●
Joint contact forces ● ● ● ●
Segmental orientation ● ● ● ●
Joint angles ● ● ● ●
Muscle forces ● ● ● ●
Anatomical trajectories ● ● ● ●
Joint ranges of motion ● ● ● ●
Muscle lengths ● ● ● ●
Centre of mass position ● ● ● ●
Joint torques ● ● ● ●
Muscle contraction rates ● ● ● ●
Body energy/power ● ● ● ●
Ground reaction forces ● ● ● ●
Muscle energy/power ● ● ● ●
Comparative analysis of multiple tasks and multiple people ● ● ● ●
Continuous analysis performing calculations every fraction of a second ● ● ● ●
Dynamic analysis to calculate loading and torques within the body ● ● ● ●
Input of data activities ● ● ● －
Analysis and display of EMG signals － ● － －
Integration of EMG signal with Motion capture, video and biomechanical analysis － ● － －
Sensitivity analysis to the workplace variables － － ● －
REBA, RULA scores, the NIOSH revised lifting equation, ISO11228, spinal compression and shear forces, cumulative forces and cumulative torques － － ● －
Pre-loaded with example activities － － － ●
インターフェース BoB/Research BoB/EMG BoB/Ergo BoB/Teaching
C3D using the Helen Hayes marker set ● ● ● －
Real time streaming from MVN Analyze Plus/Pro: This requires optional streaming module ● ● ● －
CALC from Perception Neuron ● ● ● －
BVH in Biovision, Motion Builder and Rokoko variants ● ● ● －
HPF from Delsys for EMG signals ● ● ● －
Text files generated by any EMG equipment ● ● ● －
CSV of Euler joint angles ● ● ● －
